With top pressure plate which holds down light and high pallet loads securely during wrapping operation. PLC controlled , 3 levels of wrapping can be set; top, middle and bottom Specification can be made according to the customer's requirement Custom design available.
Power Supply 110V/220V Warpping Height 2100 mm pressing plate pneumatic 5kg/cm2 adjustable Speed 15rpm/min adjustable Weight 420 kgs Loading weight 2000kgs Size L2700 x W1500 x H2850 m/m
PLC controlled, can be set up for 3 levels of wrapping top, middle and bottom can also be manually operated. 3 sets of limit switches to ensure operation safety. Slow and smooth starting turntable to safeguard pallet load. auto tear off design. Specification can be made according to the customer's requirement.
Power Supply 3?, 220/440V , 50/60Hz Warpping Height 2100mm Turntable Diameter 1500mm Turntable Speed 15rpm adjustable Weight 360kgs Load 2000kgs Size L2700 x W1500 x H2711 m/m
[Taiwan]
Movable, compact, and easy mobility. Save time, Labor & Space. Top & bottom wrapping sensored by photoelectric detection, 2 sets of safety protection switches to protect both machine and the operator. AC/AD power supply(fully charged battery can wrap 45 pallets).
Wrapping Size L1300 x W1300 x H1600 m/m (Diagonal 1800m/m) Wrapping Speed 0~5M/min adjustable PE Size Core dia 76m/m Machine Size L1690 x W1020 x H2180 m/m Machine Weight 250kg
[Taiwan]
Movable, compact, and easy mobility. No forklift required during operation. Top & bottom wrapping sensored by photoelectric detection, 2 sets of safety protection switches to protect both machine and the operator.
Wrapping Size L1300 x W1300 x H1600 m/m (Diagonal 1800m/m) Capacity 2000kg Wrapping Speed 0~5M/min adjustable PE Size Core dia 76m/m PE Thickness 15u~35u Machine Size L1900 x W2000 x H2150 m/m Machine Weight 159kg
[Taiwan]
Erect and forms carton; folds and seals bottom flaps fully automatically. Horizontal filling magazing design. delivers and feeds flat unfolded cartons consistently. User friendly and easy to adjust handle for cartons of various specifications. Custom Design Available.
Power Supply 110/220V , 50/60Hz , 1Phase Carton Size L120~600 , W150~500 , H150~500 mm Sealing Capacity 6~12 Cases/Min Tape Width 2"(2 1/2" , 3" Optional) Table Height 630mm (Adjustable Range 600~700mm) Air pressurec 5 kg/cm2 Weight 500 kgs Size L3100 x W1050 x H1800 mm
[Taiwan]
Standard components,Easy to maintain. Folds upper and lower flaps automatically. Driven by side belts, suitable for various cartons. Standard components, easy to maintain.
Power Supply 110/220V , 50/60Hz , 1Phase Carton Size L200~500 , W150~500 , H150~500 mm Sealing Capacity 20 case/hour Tape Width 2"(2 1/2" , 3" Optional) Table Height 600mm (Adjustable Range 580~720mm) Air pressure 5 kg/cm2 Weight 195 kgs Size L1030 x W870 x H1360 mm
[Taiwan]
Automatically folds top, bottom and side flaps speedily and smoothly Driven by 4 sets os belts: top, bottom and sides. Adopts pneumatic pressure to fold side flaps, which makes folding easier. Easy to operate, standard components available. Custom Design Available.
Power Supply 110/220V , 50/60Hz , 1Phase Carton Size L200~600 , W150~500 , H150~500 mm Sealing Capacity 1~15 Cases/Min Tape Width 2"(2 1/2" , 3" Optional) Table Height 630mm (Adjustable Range 600~700mm) Air pressure 5 kg/cm2 Weight 260kgs Size L1680 x W810 x H1640 mm
