¡€Cryptographic security for copyrighted data based on proven security concepts from DVD audio
¡€High transfer rate for fast copy/download
¡€High storage capacity
¡€Non-volatile solid-state; no moving parts maximizes battery power. Data is not lost when power is turned off
¡€Low battery consumption to maximize battery life in small portable devices
¡€User selectable mechanical write protect switch on the exterior card casing
¡€New SD Card slots will accept existing MultiMediaCards, allowing an easy migration path for future SD Cards
¡€Operating shock rating of 2,000Gs, equivalent to a 10-foot drop to the floor
¡€Unfazed by drastic weather conditions ranging from blistering heat to freezing cold
¡€Security level complies with Secure Digital Music Initiative (SDMI) portable device requirements
¡€The SD Card weighs approximately 1.5g, is 32mm x 24mm, and is 2.1mm thick
DimensionsCard: 32mm(L)*24mm(W)*2.1mm(H)
Weight: 2g(typical)
PerformanceData Transfer rate up to 2MB/sec
Power consumption
Operating CurrentRead: <80mA
Write: <80mA
Standby: 250uA
Environment conditions
Operating Voltage 2.6V ~ 3.7V
Operating Temperature -25?C to 85?C
Storage Temperature -40¶È to 85¶È
Relative humidity: 8% to 85%
Ruggedness
Shock, operating or storage 1000-G, any axis or direction.Vibration, operating or storage 15-G peak to peak,0.5 sine wave, 10~500Hz, any axis or direction.
|
|
|
| |
