Product Model
TAIMES 3206H SOLVENT PRINTER
Printhead
SPT510-35PL
Number of Printhead
6 Heads
Maximum Print Width
3200mm
Output (m2/h)
Print Mode
Standard Output (m2 /h)
Type :
Solvent Ink / ECO-Solvent Ink
Color :
6 Colors( C , M , Y , K , Lc , Lm )
Capacity :
5L Per Main Tank of Each Color
Ink Supply System :
Low Ink Detector, Auto or Manual Ink Supply System
Media
Width :
3300mm
Type :
Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Auto Media Feeding System
Equipped ( Max. Media Weight 80kg )
Auto Cleaning System
Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System
Equipped
Clamp
Equipped
Print Interface
USB2.0
Printhead Height
2 to 4 mm Above Media Adjustable
RIP Software
Maintop , UltraPrint , PhotoPrint , Topaz , Wasatch , Caldera
Input Power
AC 220V ,50Hz/60Hz
Machine Dimension
L4,300 x W800 x H1,160 mm Net Weight : 340Kg
Package Dimension
L4,500 x W1,100 x H900 mm Gross Weight : 420Kg
Operation Environment
Temperature: 20~28 o C Humidity: 40%~60% |
|
|
| |
